SH-6540 |
|||||||||||||||||||||||||||||||||||||||||
|
Specification |
|||||||||||||||||||||||||||||||||||||||||
| *Heavy-duty steel electroplated for chassis | |||||||||||||||||||||||||||||||||||||||||
| PS/2
KVM switch (108LD/108HD/116HD) -Supported OS DOS,Win NT/9x/2000/Me/XP,Linux,Unix,Novell,Free BSD. -Up to 8,16 Keyboard/VGA/Mouse inputs (8,16 PCs) -Cascade control Max. up to 4096 PCS -PC port keep alive capability, KVM powering down all PCs still keep active. -Intelligent keyboard and mouse simulation, all PCs can booting in the same time. -PS/2 and Serial Mouse Emulation Provided for System Bootup -No software Required-Computer selection Via Pushbuttons, Hot keys, or OSD( On Screen Display) -Quick View scan mode for monitoring selected computers -Hot Pluggable-add or remove computer for maintenance without powering down the switch . -Support Microsoft IntelliMouse (Pro), Optical Mouse, Logitech Mouse Man, Wheel Mouse, Scroll Point.. -Security lock function. (OSD) -Built-in 3 languages OSD controls. (Germany, French, English) -Auto Scan interval 5~255 sec. -Supports VGA resolution up to 1920 x 1440 VESA DDC1/2B compatible (108A/116A/208A/216A) -Up to 8/16 Keyboard/VGA/Mouse inputs (8/16PCS) -Cascade control up to 128 PCS -No software Required-Computer selection Via Hot keys, or OSD( On Screen Display) -Quick View scan mode for monitoring selected computers -Hot Pluggable-add or remove computer for maintenance without powering down the switch . -Auto Scan interval 3~60 sec. -Support eight characters password protection and search PC server name. -Built-in one extra daisy chain port and no waste any PC port. -Support one CAT5 remote console up to 500 feet away from KVM switch.(208A/216A only) USB KVM Switch (108AU/116AU) -Up to 8/16 VGA/USB inputs (8/16PCS) -USB 1.1 Specification compliant. -Cascade control up to 128 PCS -No software Required-Computer selection Via Hot keys, or OSD( On Screen Display) -Quick View scan mode for monitoring selected computers -Hot Pluggable-add or remove computer for maintenance without powering down the switch . -Auto Scan interval 5~99 sec. -Support UHCI, OHCI USB interface. -Support Win98/98SE/ME/2000/XP,WinNT, HP Unix, Linux, Sun Solaris, MAC O.S 8.6 or later version. -Manage multiple PCs, G3/G4 MACs, SUN Microsystems with USB port from one USB keyboard, USB Mouse and Monitor. -Support eight characters password protection and search PC server name. -Built-in one extra daisy chain port and no waste any PC port. |
|||||||||||||||||||||||||||||||||||||||||
| *Supports VGA resolution up to 1920 x 1440 | |||||||||||||||||||||||||||||||||||||||||
| Power Supply: | |||||||||||||||||||||||||||||||||||||||||
| *5V~12V DC input ( includes universal AC input, 9VDC output power adapter.) | |||||||||||||||||||||||||||||||||||||||||
| Color : | |||||||||||||||||||||||||||||||||||||||||
| *Available in black. (Colors available for OEM) | |||||||||||||||||||||||||||||||||||||||||
| Option | |||||||||||||||||||||||||||||||||||||||||
| *UL-2919 rated 3-in-1 cables set with VGA, keyboard (PS/2), Mouse (PS/2) (1.8M,3M,6M Optional) | |||||||||||||||||||||||||||||||||||||||||
| Dimensions | |||||||||||||||||||||||||||||||||||||||||
| SH-6540-(XXX) | |||||||||||||||||||||||||||||||||||||||||
| W.482mm x D.150mm x H.44mm | |||||||||||||||||||||||||||||||||||||||||
| N.W. 4.5 KGS | |||||||||||||||||||||||||||||||||||||||||
| G.W. 6 KGS | |||||||||||||||||||||||||||||||||||||||||
| CUFT. 1.7 | |||||||||||||||||||||||||||||||||||||||||
| Ordering Information: | |||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||
